1993 Mazda Rx-7 Turbo on 2040-cars

Auto blog

Mazda patent shows rotary placement in complex AWD hybrid layout

If we were playing alt-powertrain Bingo, a recent Mazda patent application filed in Japan would be one or two letters from victory. What's exciting about the patent, discovered by Japanese outlet T's Media via Motor Trend, is that while it makes a case for an internal combustion engine of any configuration, one of the drawings showing a rotary engine. The wild bit is that the whole powertrain comprises the ICE, a transaxle, two tiny in-wheel electric motors turning the front wheels, a third electric motor in the driveline, a capacitor, a lithium-ion battery, and three inverters. Motor Trend parsed the mechanics, and the way it reads, Doc Brown couldn't have done a better job. The rotary engine at the front turns the rear wheels, but not directly. Instead of a flywheel on back of the engine, the drawing shows a 25-kW electric motor and an inverter, then a driveshaft running to the transaxle. Along the axis of the transmission tunnel in a normal car, between the inverter and the transaxle, lies a 3.5-kWh battery running at 48 volts. MT writes that the electric motor can add its output to the ICE output to drive the rear wheels, or the e-motor can turn the rear axle on its own. Up front, two inverters and a double-layer capacitor join the ICE in the engine bay. The capacitor and tiny hub motors in the front wheels run at 120 volts, a higher voltage than the rest of the electrical system, so that the small in-wheel motors can generate the same torque as a larger motor running at a lower voltage. The AWD system acts on-demand. Given the signal, the capacitors discharge their energy to the wheel motors, and recover energy from braking. When the capacitors are at full charge, they send excess regen energy to the lithium-ion battery; conversely, the battery can recharge the capacitors when they're low and the front hub motors need power. The patent explains that the ICE works with the rear e-motor to drive the rear wheels at low speeds, the front motors called on to "generate an output only when a large output is required in the high vehicle speed range." The rather complicated system is focused on providing the benefits of a hybrid system and all-wheel drive, but at lower weight than one would expect. A rotary serves due to its compactness, but one of the drawings shows an engine with a V layout. Hub motors get dinged for adding unsprung weight, hence the small motors here.

Mazda CX-5, Mazda6 and Mazda3 could stall due to software glitch

Mazda is recalling 262,220 vehicles due to a software error that could cause the engine to unexpectedly stall out. The recall affects 2018-2019 CX-5 crossovers, 2018-2019 Mazda6 sedans and 2019 Mazda3 models.  According to NHTSA recall No. 19V497000, which was filed June 27, a programming issue in the powertrain control module (PCM) on select Mazda vehicles could cause the engine to shut down. More specifically, "the software controlling the hydraulic valve clearance adjuster may operate improperly when transitioning from cylinder deactivation to full cylinder activation modes." This could potentially cause the intake valve rocker arm to come out of position and hit something else in the engine. If this occurs, the engine could misfire, the engine could lose power, and the Malfunction Indicator Light would be triggered. The recall affects 143,004 2018 CX-5s, 81,236 2019 CX-5s, 18,295 2018 Mazda6s, 2,551 2019 Mazda6s, and 17,134 Mazda3s. Some cars from those model years received the improved software at the factory and won't be affected by the recall. Although the first report of a related issue was chronicled in January 31, 2018, no injuries tied to the problems have been reported. Mazda is expected to start its recall on or before August 26, 2019, and will reprogram the PCM with improved hydraulic valve adjustment control programming for free. Contact Mazda at 1-800-222-5500, reference No. 3719F, for more information.

Junkyard Gem: 1989 Mazda MX-6 GT Turbo

The Mazda MX-6 is best-known in the United States as the sibling (or maybe first cousin) of the Ford Probe, which almost became the successor to the Fox Mustang. The MX-6 and Probe were well-engineered and very quick for the era, but never enjoyed great American-market sales success. Here's a rare first-generation MX-6 GT that I photographed last week in a Denver self-service yard. 145 turbocharged horsepower was pretty good for 1989, when a new Honda Prelude Si had 135 horses and the far more expensive BMW 325i ($24,650 for the 325i coupe versus $14,499 for the MX-6 GT Turbo) had 168. This one doesn't have the optional four-wheel steering, but it does have the three-way adjustable suspension. If you drove a turbocharged car in 1989, you needed a nine-band equalizer with analog sliders on the radio. It was the law. It's not rusty, but at 205,575 miles it's worn out. This content is hosted by a third party. To view it, please update your privacy preferences. Manage Settings. The Japanese-market version was known as the Capella C2, and it boasted some great TV commercials. This content is hosted by a third party. To view it, please update your privacy preferences. Manage Settings. "A better value in high-performance luxury sports coupes comes from our intense commitment to your total satisfaction." As always, the US-market TV ads are less interesting than their Japanese counterparts. Related Video: Featured Gallery Junked 1989 Mazda MX-6 GT Turbo View 21 Photos Image Credit: Murilee Martin / AOL Auto News Mazda Coupe Classics
