1993 Mazda Rx-7 Ssm Twin Turbo on 2040-cars

Auto blog

Mazda patent shows rotary placement in complex AWD hybrid layout

If we were playing alt-powertrain Bingo, a recent Mazda patent application filed in Japan would be one or two letters from victory. What's exciting about the patent, discovered by Japanese outlet T's Media via Motor Trend, is that while it makes a case for an internal combustion engine of any configuration, one of the drawings showing a rotary engine. The wild bit is that the whole powertrain comprises the ICE, a transaxle, two tiny in-wheel electric motors turning the front wheels, a third electric motor in the driveline, a capacitor, a lithium-ion battery, and three inverters. Motor Trend parsed the mechanics, and the way it reads, Doc Brown couldn't have done a better job. The rotary engine at the front turns the rear wheels, but not directly. Instead of a flywheel on back of the engine, the drawing shows a 25-kW electric motor and an inverter, then a driveshaft running to the transaxle. Along the axis of the transmission tunnel in a normal car, between the inverter and the transaxle, lies a 3.5-kWh battery running at 48 volts. MT writes that the electric motor can add its output to the ICE output to drive the rear wheels, or the e-motor can turn the rear axle on its own. Up front, two inverters and a double-layer capacitor join the ICE in the engine bay. The capacitor and tiny hub motors in the front wheels run at 120 volts, a higher voltage than the rest of the electrical system, so that the small in-wheel motors can generate the same torque as a larger motor running at a lower voltage. The AWD system acts on-demand. Given the signal, the capacitors discharge their energy to the wheel motors, and recover energy from braking. When the capacitors are at full charge, they send excess regen energy to the lithium-ion battery; conversely, the battery can recharge the capacitors when they're low and the front hub motors need power. The patent explains that the ICE works with the rear e-motor to drive the rear wheels at low speeds, the front motors called on to "generate an output only when a large output is required in the high vehicle speed range." The rather complicated system is focused on providing the benefits of a hybrid system and all-wheel drive, but at lower weight than one would expect. A rotary serves due to its compactness, but one of the drawings shows an engine with a V layout. Hub motors get dinged for adding unsprung weight, hence the small motors here.

Mazda6 Skyactiv-D Racecar ready to bring diesel to Grand-Am

It may not be quite as radical as some of the company's past rotary racers, but the new Mazda6 Skyactiv-D racecar does have a notable powertrain underhood: the automaker's brand-new clean diesel four-cylinder engine.
Three of these new diesel-powered Mazda6 racers will take to the track in the Grand-Am GX class of the upcoming 2013 Rolex 24 at Daytona on January 26, with five drivers on each team. The car you see above, number 70, is sponsored by Mazda's longtime motorsports partner, SpeedSource.
Check out our full gallery of high-res images live from the 2013 Detroit Auto Show above and feel free to read through the related press release from Mazda below.

2014 Mazda6: Introduction

An Extended Stay With The Sexy Six
The new-for-2014 Mazda6 sedan is more than just a pretty face. For Mazda, it marks the company's best effort yet at competing in the highly competitive midsize sedan segment, all the while staying true to the brand's core value of offering high levels of driver involvement above all. We certainly came away impressed after our first drive of the sleek Six in France last fall, and we knew right from the start that this would be a car we'd want to spend a lot of time with back here at home.
So with that in mind, the folks at Mazda graciously agreed to loan us the fully loaded Soul Red tester you see here for a one-year stay in the Autoblog long-term garage. Because of how important this car is to the segment, and to Mazda as a brand, we know there's going to be a lot to talk about it over the next 12 months. Right now, though, allow us to introduce you to the newest member of our long-term family.
