2000 Jeep Grand Cherokee Laredo Awd Quad Trac 4x4 Auto I6 4.0 Power Ac 4 Door on 2040-cars

Identification data

Production/sales period of cars with this particular specs:

mid-year 1999 - mid-year 2000

Modelyears:

2000

Country of origin:

USA

Make:

Jeep

Model:

Grand Cherokee 2nd generation (WJ-series)

1999-2005

Submodel:

Grand Cherokee WJ-series 4WD

1999-2005

Optional equipment:

EEC segmentation:

J (E) (sport utility cars and off-road vehicles - executive cars)

Subsegment:

J3-4WD (4WD executive sport utility cars and off-road vehicles)

Class:

mid-size off-road / SUV (sport utility vehicle)

Body style:

sport-utility wagon

Doors:

5

Traction:

4x4 full-time (Selec-Trac NV242, 48/52 torque split planetary differential, fully locked mode in low and high range, front can be disengaged manually)

Dimensions & capacities

Length:

4610 mm / 181.5 in

Width:

1836 mm / 72.3 in

Height:

1763 mm / 69.4 in

Wheelbase:

2690 mm / 105.9 in

Front track:

1511 mm / 59.5 in

Rear track:

1511 mm / 59.5 in

Ground clearance:

211 mm / 8.3 in

Turning circle btw. walls:

Turning circle btw. curbs:

11.1 m / 36.4 ft

Drag coefficient claimed:

0.45

Drag coefficient estimated by a-c:

Legroom:

1st row:

41.4 in / 1052 mm

2nd row:

35.3 in / 897 mm

3rd row:

Shoulder room:

1st row:

58.9 in / 1496 mm

2nd row:

57.8 in / 1468 mm

3rd row:

Headroom:

1st row:

39.7 in / 1008 mm

2nd row:

39.5 in / 1003 mm

3rd row:

Hiproom:

1st row:

2nd row:

Claimed EPA passenger volume:

100 cu ft / 2.83 m3

Calculated EPA passenger volume:

102.7 cu ft / 2.91 m3

Interior length:

Interior width:

Interior height:

Trunk (cargo) capacity claimed:

Trunk (cargo) capacity SAE:

1104 / 2047 / dm3

39 / 72.3 / cu ft

Trunk (cargo) capacity VDA:

Boot length:

Boot length max.:

Boot width:

Boot width min. (between wheel arches):

Boot height:

Loading height:

Approach angle (deg):

36.7

Departure angle (deg):

28.6

Ramp angle (deg):

22.6

Weights

Curb weight (without a driver):

Weight distribution f/r (%):

Dry weight:

Shipping weight:

Curb weight estimated:

1764 kg / 3890 lbs

Gross vehicle weight rating GVWR:

2427 kg / 5351 lbs

Payload:

Payload estimated:

663 kg / 1460 lbs

Towing weight:

unbraked:

braked:

Sales markets

Powertrain

Engine manufacturer:

Chrysler PowerTech 4.0L (development of AMC 242 I6)

Engine type:

spark-ignition 4-stroke

Fuel type:

petrol (gasoline)

Fuel system:

indirect injection

Charge system:

naturally aspirated

Valves per cylinder:

2

Valves timing:

Additional features:

sequential fuel injection

OHV

Emission control:

3-way cat, Lambda-Sensor

Emission standard:

Cylinders alignment:

Line 6

Displacement:

3956 cm3 / 240.7 cui

Bore:

98.4 mm / 3.87 in

Stroke:

86.7 mm / 3.41 in

Compression ratio:

8.8 : 1

Power net:

145.5 kW / 198 PS / 195 hp (SAE net)

/ 4600

Torque:

312 Nm / 230 ft-lb

/ 3000

Power gross:

Torque gross:

Redline rpm:

Fuel capacity:

78 liter / 20.6 U.S. gal / 17.1 imp. gal

Drivetrain

Gearbox:

Chrysler 42RE

Transmission type:

automatic

Number of gears:

4

Gear ratios (overall):

I

2.74 (9.73)

II

1.54 (5.47)

III

1 (3.55)

IV

0.69 (2.45)

V

()

VI

()

VII

()

VIII

()

R

2.1

Speed range

(max speed on gears,

top gear value theor.):

(km/h/mph)

I:

72 / 45

II:

128 / 80

III:

197 / 122

IV:

286 / 178

V:

/

VI:

/

VII:

/

VIII:

/

1000rpm speed:

(km/h/mph)

I:

14.4 / 8.9

II:

25.6 / 15.9

III:

39.5 / 24.5

IV:

57.2 / 35.6

V:

/

VI:

/

VII:

/

VIII:

/

Torque converter factor:

Final drive ratio std:

3.55

optional:

3.73

transfer case 2.72/1

Front brakes:

Rear brakes:

Standard tires:

P 225/75 SR 16

Performance - Factory claim

Top speed:

0-60 mph (s):

0-100 km/h (s):
