2016 Mclaren 570 on 2040-cars

Auto blog

McLaren's novel MP4-31 suspension revealed

Giorgio Piola and Matt Somerfield analyze the innovative suspension design on McLaren's new MP4-21 Formula 1 car. McLaren has openly talked about there being some 'innovation' on its 2016 Formula 1 car when the first images of the Honda-powered machine emerged on Sunday. And while there were already hints from the launch pictures about an aggressive suspension solution, it was only when the new car hit the track at Barcelona on Monday that such concepts have been confirmed. As Giorgio Piola's exclusive photograph below shows, McLaren has been very bold with its front suspension design - with the upper rear arm much lower than is normal. McLaren MP4-31 detail Photo by: Giorgio Piola It was interesting too that the team had fitted additional sensors on both of the rear arms of the wishbones to help monitor data from this area during the first day of testing. Suspension thinking Rather than an assimilation of the conjoined lower wishbone (see below), pioneered by Mercedes in 2014 and adopted elsewhere, we can see that McLaren is thinking independently. Mercedes AMG F1 Team W07 detail Photo by: Giorgio Piola The front suspension can have a marked effect on how the airflow moves down and around the rest of the car and so the teams have to carefully plan its layout, as it is exceptionally difficult to change once designed. McLaren is clearly searching for previously untapped aerodynamic performance, with the rear profile of each of the wishbone arms placed virtually on top of one another. The upper of the two is slung lower than usual, meaning it should work in unison to pull the airflow down and around the sidepod, rather into or over it. These early tests, with the sensors placed on the wishbones, are used to correlate the on track data with what the team expected when the car was tested both kinematically and aerodynamically in CFD, the wind tunnel and on the seven-post shaker rig. Red Bull push The pitlane launch of the 2016 Red Bull challenger, amongst a frenzy of other machines, means a more detailed analysis of it will follow later. However, one area of interest, like the McLaren, is the front suspension. It has converged on the idea of conjoining the lower wishbone element but, as is usual for Red Bull, it has taken it to extremes, with only a small opening now available at the inboard sections. Of course this is done for its aerodynamic purposes with the large surface area allowing a smoother transition of the airflow.

Xcar takes the wheel of McLaren's 650S

The list of supercars that Xcar has driven and documented is as long and distinguished as, um, a large yacht. It's done videos on Ferraris, Lamborghinis, Bugattis, Porsches, Aston Martins, you name it. And it drove the McLaren MP4-12C nearly two years ago, but for its latest video, it's revisited Woking to sample the newer 650S. An evolution of the 12C that put McLaren Automotive back on the map, the 650S is faster, more powerful, handsomer and better in every way we could think of than the model it replaces. We found out that much when we drove it in Spain upon its launch a year ago, and reviewed it in full a few months later. But don't take our word for it: watch the footage from the cinematographical artisans in the video above.

Race recap: 2016 Belgian Grand Prix is a dozen angry laps

The calm of the Formula One summer break ended with the tumult of the Belgian Grand Prix. The first two days included unusual tire pressures and grid penalties; Mercedes-AMG Petronas' Lewis Hamilton started 21st because of a 55-place grid penalty for engine and gearbox changes, McLaren's Fernando Alonso started 22nd due to a 60-place penalty for the same offenses. The bedlam rolled right into what was effectively an 11-or 12-lap race. Mercedes driver Nico Rosberg took off from pole and the cameras barely bothered with him until he took the checkered flag 44 laps later. Red Bull's Max Verstappen bogged from second on the grid, got swallowed by Ferrari's Sebastian Vettel and Kimi Raikkonen on the way to Turn 1, then attempted to recover by sticking his Red Bull's nose between Raikkonen's sidepod and the apex at the first corner. Vettel, who didn't see Verstappen, turned into La Source leaving only enough room for Raikkonen. Three cars don't fit in a space for two cars. Vettel spun, Raikkonen and Verstappen clobbered one another and all three drivers had to pit for repairs. Force India's Nico Hulkenberg zig-zagged his way into second ahead of Red Bull's Daniel Ricciardo, Williams' Valtteri Bottas, and Sergio Perez in the second Force India. On Lap 6 Kevin Magnussen lost his Renault at Raidillon at the top of Eau Rouge and flew backward into an enormous crash. Magnussen escaped with just a cut ankle. The Safety Car paraded the field for four laps before officials red flagged the race to repair the barriers. When racing resumed on Lap 10, Rosberg led Ricciardo, Hulkenberg, Alonso, and Hamilton. Ricciardo stayed ahead of Hamilton to keep second place at the end of the race, Hamilton easily got around Alonso and Hulkenberg to lock up third. Hulkenberg – who'd given up second to Ricciardo by pitting during the Safety Car period – earned another career-best fourth position ahead of teammate Perez in fifth, followed by Vettel and Alonso on recovery drives, Bottas, Raikkonen, and Felipe Massa taking 10th in the second Williams. Rosberg reignited his Driver's Championship charge with the victory, closing to nine points of leader Hamilton. We could argue that Hamilton had an equally good day by driving from 21st to third, limiting his loss to only 10 points. About that Verstappen, though... We've seen far more experienced drivers attempt the same move Verstappen made into Turn 1 – Raikkonen on Bottas in Russia in 2015, for instance.
